Series    HPE 1410 Switch Series
Related document    US Quickspecs
Port and slots
I/O ports and slots
16 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX) Duplex: half or full
Supports a maximum of 16 autosensing 10/100 ports

Memory and processor
16 Kb EEPROM; packet buffer size: 2 Mb
Mounting and enclosure
Mounts in an EIA standard 19-inch telco rack (hardware included); wall, desktop and under-table mounting
Performance
100 Mb Latency    < 10.6 µs (LIFO 64-byte packets)
Throughput    up to 2.3 Mpps (64-byte packets)
Switching capacity    3.2 Gbps
MAC address table size    8192 entries
Environment
Operating temperature    32°F to 104°F (0°C to 40°C)
Operating relative humidity    15% to 95%, noncondensing
Non-operating/ Storage temperature    -40ºF to 158ºF (-40ºC to 70ºC)
Non-operating/ Storage relative humidity    15% to 90% @ 149°F (65°C), noncondensing
Electrical characteristics
Frequency75 BTU/hr (395.63 kJ/hr)    50/60 Hz
Maximum heat dissipation    37 BTU/hr (39.03 kJ/hr)
AC Voltage    100 - 240 VAC
Current    0.3 A
Maximum power rating    3.6 W
Safety
UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009

Emissions
FCC Rules Part 15, Subpart B Class A
Immunity
Generic

EN 55022 CISPR 22

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3

EFT/Burst

IEC 61000-4-4

Surge

IEC 61000-4-5

Conducted

IEC 61000-4-6

Power frequency magnetic field

IEC 61000-4-8

Voltage dips and interruptions

IEC 61000-4-11

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Protocol

IEEE 802.1p Priority
IEEE 802.3ab 1000BASE-T Gigabit Ethernet over twisted pair (10/100/1000 models only)
IEEE 802.3i 10BASE-T Ethernet over twisted pair
IEEE 802.3u 100BASE-TX Fast Ethernet, 100BASE-FX with autonegotiation
IEEE 802.3x Flow Control

Physical characteristics
Dimensions    8.21(w) x 4.21(d) x 1.73(h) in (20.85 x 10.69 x 4.39 cm) (1U height)
Weight    1.43 lb (0.65 kg)
