Standards IEEE 802.3/3u/3x, CSMA/CD, TCP/IP
Basic Functions Line Speed Exchanges
MAC Address Self-learning
Supports IEEE 802.3x flow control in Full Duplex mode
Supports Back Pressure flow control in Half Duplex mode
Backplane Bandwidth 1Gbps
MAC Address Table 1k
Packet Forwarding 14880pps ( 10BASE-T)
148800pps ( 100BASE-TX)
Forwarding Mode Store and Forward
Ports Five 10/100Mbs RJ45 Self-adaptive Ports / Auto MDI / MDIX
Cables 10BASE-T: 3, 4, 5 or above class crossover Ethernet cable (Maximum 250 Meters)
EIA / TIA-568 100u straight through cable (Maximum 250 Meters)
100BASE-TX: 4, 5 or above class crossover Ethernet cable (Maximum 150 Meters)
EIA / TIA-568 100u straight through cable (Maximum 150 Meters)
LED Indicators Power indicator, Port indicators (Link / Act )
Environment Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Operating Humidity: 10% to 95% RH, Non-condensing
Storage Humidity: 5% to 95% RH, Non-condensing
