- Intel® B365 Chipset
- 4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
- Dual Channel Memory Architecture
- Supports Intel® Extreme Memory Profile (XMP)
- * The maximum memory frequency supported varies by processor
- ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
- Graphic
- Integrated Graphics Processor- Intel® HD Graphics support
- Multi-VGA output support : HDMI/DVI-D/D-Sub ports
- - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 30 Hz
- - Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
- - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
- Maximum shared memory of 1024 MB (for iGPU exclusively)
- Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
- Expansion Slots
- 1 x PCIe 3.0 x16 (x16 mode)
- 2 x PCIe 3.0/2.0 x1
- Storage
- Intel® B365 Chipset :
- 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
- 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
- 6 x SATA 6Gb/s port(s), gray
- Support Raid 0, 1, 5, 10
- Intel® Rapid Storage Technology supports
- Intel® Optane™ Memory Ready
- LAN
- Realtek® RTL8111H, 1 x Gigabit LAN
- ASUS LAN Guard
- Audio
- Realtek® ALC887 8-Channel High Definition Audio CODEC
- - Supports : Jack-detection, Front Panel Jack-retasking
- Audio Feature :
- - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
- - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
- - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
- * Choose the chassis with HD audio module in front panel to support 8-channel audio output.
- USB Ports
- Intel® B365 Chipset :
- Intel® B365 Chipset :
- 7 x USB 3.1 Gen 1 up to 5Gbps port(s) (5 at back panel, , 4 x Type-A+1 x Type-C, 2 at mid-board)
- Intel® B365 Chipset :
- 4 x USB 2.0/1.1 port(s) (4 at mid-board)
- Special Features
- ASUS 5X Protection III :
- - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
- - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
- - ASUS Overvoltage Protection: World-class circuit-protecting power design
- - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
- - ASUS DIGI+ VRM: Premium components provide better power efficiency
- ASUS OptiMem：
- - Optimem (Improved DDR4 stability)
- ASUS EPU :
- - EPU
- ASUS Exclusive Features :
- - AI Suite 3
- - Ai Charger
- - PC Cleaner
- ASUS Quiet Thermal Solution :
- - Stylish Fanless Design Heat-sink solution
- - ASUS Fan Xpert 2+
- ASUS EZ DIY :
- - ASUS CrashFree BIOS 3
- - ASUS EZ Flash 3
- - ASUS UEFI BIOS EZ Mode
- ASUS Q-Design :
- - ASUS Q-DIMM
- M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)
- Back I/O Ports
- 1 x PS/2 keyboard (purple)
- 1 x PS/2 mouse (green)
- 1 x DVI-D
- 1 x D-Sub
- 1 x HDMI
- 1 x LAN (RJ45) port(s)
- 1 x USB 3.1 Gen 1 USB Type-CTM up to 5Gbps
- 4 x USB 3.1 Gen 1 Type-A
- 1 x 8-channel Audio I/O
- Internal I/O Ports
- 1 x Aura RGB Strip Header
- 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
- 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
- 2 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices
- 1 x TPM header
- 1 x LPT header
- 1 x COM port(s) connector(s)
- 6 x SATA 6Gb/s connector(s)
- 1 x CPU Fan connector(s)
- 2 x Chassis Fan connector(s)
- 1 x S/PDIF out header(s)
- 1 x 24-pin EATX Power connector(s)
- 1 x 8-pin EATX 12V Power connectors
- 1 x Front panel audio connector(s) (AAFP)
- 1 x Clear CMOS jumper(s)
- 1 x System panel connector
- 1 x Chassis intrusion header
- 1 x Speaker connector
- Accessories
- User's manual
- I/O Shield
- 2 x SATA 6Gb/s cable(s)
- 2 x M.2 screws
- 1 x Supporting DVD
- Manageability
- WOL by PME, PXE
- Operating System
- Windows® 10 64-bit
- Form Factor
- mATX Form Factor
- 9.6 inch x 8.6 inch ( 24.4 cm x 21.8 cm )
