- Brand: ASUS
- Model: 90MB0TV0-M0EAYC
- Product Type: Motherboard - micro ATX
- Chipset Type: AMD A320
- Processor Socket: Socket AM4
- Max Processors Qty: 1
- Compatible Processors: Athlon, A series, Ryzen (supports 7th Generation A-series / Athlon)
- Max Size: 32 GB
- Technology: DDR4
- Bus Clock: 2400 MHz, 2133 MHz, 2666 MHz, 2933 MHz (O.C.), 3200 MHz (O.C.)
- Supported RAM Integrity Check: Non-ECC, ECC
- Registered or Buffered: Unbuffered
- Features: Dual channel memory architecture
- Max Allocated RAM Size: 2 GB
- Type: HD Audio (8-channel)
- Audio Codec: Realtek ALC887
- Compliant Standards: High Definition Audio
- Network Controller: Realtek RTL8111H
- Network Interfaces: Gigabit Ethernet
- Expansion Slots: 1 x CPU ¦ 2 x DIMM 288-pin ¦ 1 x PCIe 3.0 x16 (x16 mode (with AMD Ryzen CPU); x8 mode (with AMD 7th Generation A-series/Athlon CPU)) ¦ 2 x PCIe 2.0 x1
- Storage Interfaces: SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2
- Interfaces: 1 x LAN (Gigabit Ethernet) ¦ 4 x USB 3.0 ¦ 1 x PS/2 keyboard ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x PS/2 mouse ¦ 1 x VGA ¦ 2 x USB 2.0 ¦ 1 x HDMI
- Internal Interfaces: 4 x USB 2.0 - header ¦ 2 x USB 3.0 - header ¦ 1 x serial - header ¦ 1 x SPDIF out - header ¦ 1 x audio - header ¦ 1 x speaker - header
- Power Connectors: 4-pin ATX12V connector, 24-pin main power connector
- BIOS Type: AMI
- BIOS Features: WfM 2.0 support, Multilingual BIOS, ASUS Quiet Thermal Solution, UEFI BIOS, ASUS EZ Flash 3, SMBIOS 3.0 support, ACPI 6.1 support
- Hardware Features: ASUS Q-Design, ESD Guards, Q-DIMM, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, ASUS Fan Xpert, ASUS DIGI+ VRM, Fanless Design Heatsink, ASUS Stainless Steel Back I/O, LANGuard, ASUS Overvoltage Protection, Lighting Control, ASUS 5X Protection III, ASUS SafeSlot Core
- Included Accessories: 1 x M.2 screw, I/O back cover
- Cables Included: 2 x Serial ATA cable
- Software Included: Drivers & Utilities, ASUS AI Charger, ASUS AI Suite III
- Compliant Standards: Plug and Play
- Width: 22.6 cm
- Depth: 22.1 cm
