Mass    Approx.2.7 kg (body)
Approx. 5lb 15.2 oz (body)
Approx. 3.2 kg (with lens hood (1), eyecup (1), battery pack BP-U30 (1), SxS memory card(1))
Approx. 7lb 0.9 oz (with lens hood (1), eyecup (1), battery pack BP-U30 (1), SxS memory card (1))
Dimensions (approx W x H x D)    191.5 201.5 412 mm (Approx. 7 5/8 x 8 x 16 1/4 in.) (without protrusions)
Power Requirements    DC19.5 V (AC Adaptor), DC14.4 V (battery pack)
Power Consumption    Approx. 19.9 W (while recording with LCD Off, EVF On when the external device connector is not used.)
Approx. 20.8 W (while recording with LCD On, EVF On when the external device connector is used.)
Operationg Temperature    0C to 40C (32F to 104F)
Storage Temperature    -20C to +60C (-4F to 104F)
Battery Operating Time    With battery pack BP-U90: approx. 4 hours, 00 minutes (While recording with LCD Off, EVF On when the external device connector is not used.)
With battery pack BP-U60: approx. 2 hours, 35 minutes (While recording with LCD Off, EVF On when the external device connector is not used.)
With battery pack BP-U30: approx. 1 hours, 15 minutes (While recording with LCD Off, EVF On when the external device connector is not used.)
Recording Format (Audio)    LPCM, AC-3 (AVCHD): 2ch> LPCM (XAVC/MPEG2/AVCHD/DVCAM), Dolby Digital (AVCHD): 2ch
RECORDING FORMAT (VIDEO)
XAVC-Intra 1920x1080    59.94i: 111Mbps max, 50i: 112Mbps max, 29.97P: 111Mbps max, 25P: 112Mbps max, 23.98P: 89Mbps max
XAVC-Intra 1280x720    59.94P: 111Mbps max, 50P: 112Mbps max
XAVC-Long 1920x1080    59.94i, 50i: 50/35/25Mbps max,
59.94P, 50P, 29.97P, 25P, 23.98P: 50/35Mbps max
XAVC-Long 1280x720    59.94P, 50P: 50Mbps max
MPEG HD422 1920x1080    59.94i, 50i, 29.97P, 25P, 23.98P: 50Mbps max
MPEG HD422 1280x720    59.94P, 50P, 29.97P, 25P, 23.98P: 50Mbps max
MPEG HD420 1920x1080    59.94i, 50i, 29.97P, 25P, 23.98P: 35Mbps max
MPEG HD420 1440x1080    59.94i, 50i: 35Mbps max
MPEG HD420 1280x720    59.94P, 50P: 35Mbps max
AVCHD 1920x1080    59.94P, 50P: 28Mbps max,
59.94i, 50i, 29.97P, 25P, 23.98P: 24Mbps max
AVCHD 1280x720    59.94P, 50P: 24Mbps max
DVCAM 720x480    59.94i: 25Mbps
DVCAM 720x576    50i: 25Mbps
Lens Mount    Fixed
Zoom Ratio    25x (optical), servo/manual
Focal Length    f=3.7-92.5 mm
equivalent to 26-650 mm on 35 mm lens
Iris    F1.6 - F11 and C (close)
Focus    AF/MF selectable, 10 mm ~ (Wide), 800 mm ~ (Tele)
Image Stabilizer    ON/OFF/ACTIVE selectable, shift lens
Filter Diameter    M82 mm
CAMERA SECTION
Imaging Device (Type)    3-chips 1/3-type Exmor CMOS Sensor
Effective Picture Elements    1920 (H) x 1080 (V)
Built-in Optical Filters    Clear, 1/4~1/128 Variable
Sensitivity    F9 (typical) (1920 x 1080/59.94i mode)
F10 (typical) (1920 x 1080/50i mode)
S/N Ratio    60 dB (Y) (typical)
Shutter Speed    1/32 sec to 1/2000 sec
Slow & Quick Motion Function    1920x1080p: Frame rate selectable 1~60p (depends on Recording Format)
1280x720: 1~120P (depends on Recording Format)
Angle of view becomes smaller over 60fps.
White Balance    Preset (3200K), A,B
Wireless functions    No
NFC    No
INPUT / OUTPUT
Audio Input    XLR-type 3-pin (female) (x2)
HDMI Output    Type A (x1)
3G-SDI Output    BNC Connector (x1)
Composite Output/GENLOCK-IN    BNC Connector (x1)
Audio Output    Stereo mini jack 3.5 mm (x1)
USB    mini-B/USB2.0 Hi-speed/mass-storage (x1)
Type A/for Wireless LAN module (x1)
Type A/USB3.0 (x1) (future Update)
TC in/out    BNC Connector (x1)
Remote    Stereo mini mini jack 2.5 mm (x1)
DC Input    DC jack (x1)
Shoe    Multi Interface Shoe (x1)
Headphone Output    Stereo mini jack 3.5 mm (x1)
MONITORING
Viewfinder    0.5-type color OLED, 2.36M dots
LCD    3.5-type color LCD monitor Aspect ratio 16:9, 1.56Mdots
MICROPHONE Built-in Microphone    Omni-directional stereo electret condenser microphone
MEDIAType ExpressCard/34 slot (2) (for XAVC/MPEG2/AVCHD/DV)
SD/SDHC (1) (for Utility)
