- Brand: Gigabyte
- Model: X870E_A_ELITE_X
- Product Type: Motherboard
- Form Factor: ATX Form Factor; 30.5 cm x 24.4 cm
- Processor
- AMD Socket AM5, Supports:
- AMD Ryzen™ 9000 Series Processors
- AMD Ryzen™ 8000 Series Processors
- AMD Ryzen™ 7000 Series Processors
- Chipset: AMD X870E
- Memory
- 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB per DIMM capacity) of system memory
- Dual-channel memory architecture
- Audio: Realtek ALC1220 CODEC
- High-definition audio: 2/4/5.1/7.1-channel
- Supports S/PDIF out
- LAN
- Realtek 5GbE LAN chip (5 Gb/s/2.5 Gb/s/1 Gb/s/100 Mb/s)
- Wireless communication module
- Qualcomm Wi-Fi 7 QCNCM865
- BLUETOOTH 5.4
- 11be 320MHz wireless standard support
- USB
- CPU+ASMedia USB4 controller:
- 2 x USB4 USB Type-C ports on the back panel
- CPU:
- 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support
- Chipset+USB 3.2 Gen 1 hub:
- 4 x USB 3.2 Gen 1 ports available via internal USB headers
- Chipset:
- 1 x USB Type-C port USB 3.2 Gen 2x2 support, available via internal
- USB header (supports up to 65W PD 3.0/QC 4+ fast charging)
- 5 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 3 x USB 3.2 Gen 1 ports on the back panel
- 4 x USB 2.0/1.1 ports available via internal USB headers
- BIOS
- 1 x 512 Mbit flash memory
