- Brand: Gigabyte
- Model: X870_A_ELITE_X_ICE
- Product Type: Motherboard
- Form Factor: ATX Form Factor; 30.5 cm x 24.4 cm
- Processor
- AMD Socket AM5, Supports:
- AMD Ryzen™ 9000 Series Processors
- AMD Ryzen™ 8000 Series Processors
- AMD Ryzen™ 7000 Series Processors
- Chipset: AMD X870
- Memory
- 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB per DIMM capacity) of system memory
- Dual-channel memory architecture
- Audio
- Realtek ALC1220 CODEC
- High-definition audio: 2/4/5.1/7.1-channel
- Supports S/PDIF out
- LAN
- Realtek 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps)
- Wireless communication module
- Qualcomm Wi-Fi 7 QCNCM865
- BLUETOOTH 5.4
- 11be 320MHz wireless Standard Support
- Expansion Slots
- 1 x PCI Express x16 slot (PCIEX16)
- Memory Interface
- 1 x M.2 connector (M2A_CPU)
- USB
- CPU+ASMedia USB4 Controller:
- 2 x USB4 USB Type-C ports on the back panel
- CPU:
- 1 x USB Type-C port on the back panel, supporting USB 3.2 Gen 2
- 1 x USB 2.0/1.1 port on the back panel
- Chipset:
- 1 x USB Type-C port with USB 3.2 Gen 2x2 support, accessible via internal USB header
- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 4 x USB 2.0/1.1 ports on the back panel
- Chipset + 2 USB 3.2 Gen 1 Hub:
- 8 x USB 3.2 Gen 1 ports (4 port on the back panel, 4 ports available via internal USB headers)
- BIOS
- 1 x 512 Mbit flash memory
