- Brand: Gigabyte
- Model: B760M_D3HP
- Product Type: Motherboard
- Form Factor: Micro ATX
- Processor: For Intel processors
- Socket Type: LGA1700
- Processor Compatibility: Intel Core, Pentium Gold and Celeron 14th, 13th and 12th Generations
- Chipset
- Northbridge (Chipset): Intel B760
- BIOS UEFI AMI
- RAM
- Connection Type: DDR5
- DDR5: 4 Slots
- Maximum Memory Capacity: 256 GB
- XMP Support: Yes
- Video Settings
- Graphics Interface: PCI-E x16 4.0
- D-Sub (VGA) Output
- HDMI Output
- DisplayPort
- Audio Settings
- Audio Chipset: Realtek
- Sound: 7.1, 5.1, 2, 4
- S/P-DIF: Yes
- Connecting Drives
- Connection Interface
- SATA 3
- M.2
- Software RAID support: Yes, 0/1/5/10
- SATA3 (6 Gbit/s): 4 ports
- Network interfaces
- LAN (RJ-45): 10/100/1000 Mbps
- Number of LAN ports: 1
- Connection connectors
- USB 2.0: 6 pcs (chipset: 2 ports on the back panel, chipset+USB 2.0 hub: 4 ports available via internal USB connectors)
- PS/2: 1 pc (keyboard/mouse)
- USB 3.2 Gen 1: 6 /(chipset: 1 USB Type-C port with USB 3.2 Gen 1 support,
- available via internal USB connector; 5 USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available via internal USB connector))
- M.2 Connector: 2
- Main power connector: 24+8-pin
- Dimensions (height x width): 244 x 244 mm
