- Brand: Gigabyte
- Model: A520M_DS3H_AC
- Product Type: Motherboard
- Form Factor: Micro ATX
- Processor: For AMD Processors
- Socket Type: AM4
- Processor Compatibility: AMD Ryzen 5000 Series / Ryzen 5000 G Series /
- Ryzen 4000 G Series and Ryzen 3000 and Ryzen 3000 G Series
- Chipset
- Northbridge (Chipset): AMD A520
- BIOS: UEFI AMI
- UEFI BIOS: Yes
- RAM
- Connection Type: DDR4
- DDR4: 4 Slots
- Maximum Memory Capacity: 128 GB
- Video Settings
- Graphics Interface
- PCI-E x16 3.0
- DVI Output DVI-D
- HDMI Output
- DisplayPort
- Audio Settings
- Audio Chip Realtek
- Sound: 7.1, 5.1, 2, 4
- Drive Connection
- Connection Interface
- SATA 3
- M.2
- Software RAID support: Yes, 0/1/10
- SATA3 (6 Gbit/s): 4 ports
- Network interfaces
- LAN (RJ-45): 100/1000 Mbps
- Number of LAN ports: 1
- LAN controller model: Realtek
- Wi-Fi enabled: Yes
- Bluetooth: Yes
- Connectivity connectors
- USB 2.0: 4 pcs (chipset: 2 ports on the back panel, 2 ports available via internal USB connector)
- PS/2: 1 pc (keyboard/mouse)
- USB 3.2 Gen 1: 6
- M.2 connector: 1
- Features
- CPU fan header
- system fan headers
- clear CMOS jumper
- serial port header
- iTE I/O Controller Chip
- Support for Windows 10 64-bit
- Flash BIOS Button
- RGB LED Headers
- EasyTune utility
- RGB Fusion function
- Smart Backup feature
- Q-Flash Utility
- Front Panel Header
- Front Audio Header
- TPM Header
- Voltage detection
- Temperature detection
- Fan speed detection
- Overheating warning
- Fan failure warning
- Fan speed control
- Q-Flash Plus Utility
- Support for Windows 11 64-bit
- Internet Security
- System Information Viewer
- LAN bandwidth management software
- Main power connector: 24+8-pin
- Dimensions (Height x Width): 244 x 244 mm
